Vacuum Emulsifier by MAXWELL

Product details of the vacuum emulsifier

Product Information

The raw materials of MAXWELL vacuum emulsifier are purchased from reliable vendors. Wuxi MAXWELL Automation Technology Co., Ltd is a leading manufacturer of Industrial planetary mixers, vacuum emulsifying mixers, glue filling machines, capping machine and silicone sealant filling machines. MAXWELL has over 18 years of expertise and has developed immensely in the research, design, manufacture, sale, and service of different Mixing Machine and Filling Equipment used for various products such as lotions, creams, paste, sauces, gel, paints, epoxy resin, lithium battery slurry, grea Our vacuum emulsifier is complete in specifications. Wuxi MAXWELL Automation Technology Co., Ltd is a leading manufacturer of Industrial planetary mixers, vacuum emulsifying mixers, glue filling machines, capping machine and silicone sealant filling machines. MAXWELL has over 18 years of expertise and has developed immensely in the research, design, manufacture, sale, and service of different Mixing Machine and Filling Equipment used for various products such as lotions, creams, paste, sauces, gel, paints, epoxy resin, lithium battery slurry, grea vacuum emulsifier is produced by superior material and advanced technology. Wuxi MAXWELL Automation Technology Co., Ltd is a leading manufacturer of Industrial planetary mixers, vacuum emulsifying mixers, glue filling machines, capping machine and silicone sealant filling machines. MAXWELL has over 18 years of expertise and has developed immensely in the research, design, manufacture, sale, and service of different Mixing Machine and Filling Equipment used for various products such as lotions, creams, paste, sauces, gel, paints, epoxy resin, lithium battery slurry, grea

Product Introduce

The cover of the pot is of automatic lifting type, the materials in the water and oil pots can directly enter the emulsifying pot under vacuum through the conveying pipeline, the discharging mode is the emulsifying pot turning type and the bottom valve discharging type, etc.  The heating of the materials is realized through the electric heating pipe heating the heat-conducting medium in the pot mezzanine, and the heating temperature can be arbitrarily set and automatically controlled.

The material can be cooled by accessing the coolant in the jacket, which is easy and convenient to operate, and there is a heat preservation layer outside the jacket.  Homogenizing system and mixing system can be used separately or at the same time.  Particulation, emulsification, mixing, blending and dispersing of materials can be completed in a short time.  The part in contact with materials is made of high quality stainless steel (commonly used 304, 316L for medical use), the inner surface is mirror polished, the vacuum stirring device is hygienic and clean, and it is manufactured in accordance with the hygiene standard of GMP norms, which is the ideal cream production equipment for customers.

IMG_1462

IMG_1308

IMG_1324

微信图片_20230414162810

Working Principle

Put the materials into premix tank oil phase tank and water phase tank,after heated & mixed in water tank and oil tank, it can drawn the materials into emulsifying tank by vacuum pump. Adopting the middle stirrer & Teflon scrapers residues in emulsifying tank that sweep the residues on the wall of the tank to makes the materials wiped off become the new interface constantly.

Then the materials will cut off, compressed and fold by the blades to stir, mix and run to the homogenizer. By the strong cutting off, impact and turbulent current from the high-speed shear wheel and fixed cutting case, the materials are cut off in interstices of stator and rotor and turn to particles of 6nm-2um promptly. Because the emulsifying tank is working under the vacuum state, the bubbles that produces in the process of mixing is taken away in time.

图片1 (4)

Product Features

1

1

The all-round wall scraping mixing adopts the frequency converter for speed adjustment , so that high quality products of different processes according to customer requirements.

2

The diversified high-speed homogenizer can powerfully mix solid and liquid raw materials and can rapidly dissolve manyindis soluble materials such as AES , AESA , LSA , etc. during the liquid detergent production process so as to save energy consumpion and shorten production period.

3

The pot body is welded by imported three-layer stainless steel plate. The tank body and the pipes adopt mittor polishing , which fully conforms to GMP requirements.

4

According to customer requirement , the tank can heat and cool materials. The heating way including steam heating and electric heating. Easy to discharge , bottom direct discharge or by transfer pump.

Planetary Mixer Structure

● Double Twist Mixing Head

● Double-layer high speed dispersing head

● Scraper

● Emulsifying head ( Homogenizer head )

● The mixing head combination forms are tailored for different process.   Impeller  blade, Dispersing disc, Twist impeller and Scraper are optional.

Emulsifying machine structure diagram

In the application field of the multi-function mixer, we accumulated a wealth of experience. Our product combination include the combination of high speed and high-speed, the combination of high-speed and low-speed and the combination of low-speed and low-speed.   High-speed part is divided into high shear emulsification device, high-speed dispersion device, high-speed propulsion device, butterfly stirring device.   Low-speed part is divided into anchor stirring, paddle stirring, spiral stirring, helical ribbon stirring, rectangular stirring and so on.   Any combination has its unique mixing effect.   It also have vacuum and heating function and temperature inspect function

Product Description

1. Mixing Paddle: Two-way wall scraping and mixing :Mix materials quickly,and it is very easy to clean,saving cleaning time.

2. Tank: 3-Layer stainless steel structure pot body,GMP standard engineering,sturdy and durable,good anti-scalding effect.

Steam heating or electric heating according to customers' requests.

3. ConsoleButtons:  (Or PLC touch screen) control vacuum,temperature,frequency and time setting system

4. Homogenizer: 0-3000 rpm Homogenizer,high-speed shearing to obtain high-quality products

d3-2 (2)

0 IMG_1325

IMG_1327

d4

d2 (4)

d1 (4)

IMG_1467

IMG_1466

IMG_1363

Applications

Chemical Products

Soap,plain bar soap,long-bar soap,laundry soap,Handmade soap,cold process soap Toilet soap,Body Whitening Soap ,Organic Natural soap,Liquid Soap,Hand Washing,Shampoo, Hand Sanitizer,detergent,, conditioning shampoo.hair conditioner,liquid Shampoo , Disinfectant, Disinfectant fluid,Alcohol disinfectant,Chemical.

Personal Hygiene Products

Shower gel , Body Wash , Bath Cream , Shower Foam , Bath Gel ,Moisturizing Lotion , Body Lotion, Baby Emulsion , Emollient Lotion,Moisturizer ,,Stretch Oil , Brightening Moisturizing Emulsion , Sugar Scrub , Baby Skincare Softener , Scrub Cream ,Facial Scrub , Abrasive , Scrubs , Daily Exfoliating Cream , Facial Scrub , Cleansing Gel , Facial Cleanser , Face Wash , Cleanser , Cleansing Foam ,Facial Foam , Gentle Cleansing Lotion , Toothpaste, Dental Cream ,Collutory , Mouthwash , Collutorio , Das Mundwasser.

Skin Care Products

Toner, Toning Lotion , Astringent , Mild Lotion , Suntan Oil , Sun Screen , Suntan Lotion , Sunblock ,Sunburn Cream, Anti-Wrinkle Cream , Facial Essence , Essence , Water Gel , Night Concentrate , Hydrating Gel , Face Oil , Skin Oil , Eye Gel ,Smoothing Toner, Extra Cream , Age-delay Cream , Night Cream , Retinal Moisturizer , Cream,Neck Cream , Facial Serum ,Face Cream,Facial Cream,Petro Leum Jellly , Petrolatum, Jelly Body Cream , Ointment , Butter Cream , Shea Butter Cream,Liquid Foundation ,Liquid Makeup , Fluid Foundation , BB Cream ,Sleeping Pack , Sleeping Mask , Water Sleeping Pack , Face Mask , Facial Mask ,Cosmetic.

Food

Cubilose , Ketchup , Catchup , Tomato Ketchup , Tomato Catchup , Tomato Paste ,Salad Dressing ,Thousand Island Sauce , Peanut Butter ,Cheese , Honey , Chilli Sauce , Chilli Paste , Mushroom Organic Sauce , Bearnaise , Russian dressing ,Remoulade , Maionese , Mornay Sauce , Milk , Drink.

Other models

IMG_0922

IMG_0924

IMG_0920

5 L button (with oil pan)

IMG_1724

IMG_1760

IMG_1753

5 L touch screen (without oil pan)

Company Advantage

• MAXWELL strives to open up domestic and international markets. cosmetic makingm machine,mayonnaise making machine,vacuum emulsifying mixer,double planetary mixer,filling machine,glue filling machine,silicone sealant filling machine,vacuum planetary mixer,industrial mixer,homogenizer,lab planetary mixer,vacuum homogenizer mixer,cosmetic cream mixer machine are sold to various countries and regions around the world. They are well recognized by consumers.
• Set up in MAXWELL has established a good reputation and wide popularity in the industry through the development for years.
• Our high cost performance, standardized market operation and good after-sales service have been unanimously recognized by our customers and peers.
Contact MAXWELL to order cosmetic makingm machine,mayonnaise making machine,vacuum emulsifying mixer,double planetary mixer,filling machine,glue filling machine,silicone sealant filling machine,vacuum planetary mixer,industrial mixer,homogenizer,lab planetary mixer,vacuum homogenizer mixer,cosmetic cream mixer machine online and you may have the chance to enjoy discounts!
