Semi Automatic Syringe Solder Paste Filling Machine
Place of Origin: Wuxi,Jiangshu,China
Minimum order quantity: 1
Color: Sliver
Material: SUS304,SUS316
Packing: Wooden Case
Delivery time: 20-30 days
Product Introduce
Solder paste is a commonly used soldering aid in the field of electronic soldering and is mainly used in the manufacture of surface mount technology (SMT) and printed circuit boards (PCB).Due to the high viscosity of solder paste, which can range from 150,000 to 400,000 cps, our semi automatic solder paste filling machines are equipped with powerful pressure equipment, while accurately controlling the volume of each filling. Not every syringe filling machine can be used to fill solder paste, we designed this Solder paste filling machine according to the market demand, this equipment has been well received by customers!
Video Display
Machine Parameters
|
Model |
MAX-MW03 |
|
Filling range |
10ml-500ml (Customizable) |
|
Filling speed |
around 20pcs/minute （According viscosity and volume） |
|
Measurement accuracy |
±1% |
|
Power voltage |
AC380v 50hz or customized |
|
Dimention(L*W*H) |
1900*1000*1500mm |
|
Net weight |
350kg |
Solder Paste Filler Structure
● Solder paste tank
● Double-layer high speed dispersing head
● Scraper
● Emulsifying head ( Homogenizer head )
● Press rod in middle
● Standing rod
● Platform
● 4*Wheels
Working Principle
The semi automatic solder paste syringe filling equipment uses cylinder pressure to achieve semi-automatic assembly. Easy disassembly of connecting pipe and shunt die for easy cleaning and maintenance .
Our advantage
In the application field of the multi-function mixer, we accumulated a wealth of experience.
Our product combination include the combination of high speed and high-speed, the combination of high-speed and low-speed and the combination of low-speed and low-speed. High-speed part is divided into high shear emulsification device, high-speed dispersion device, high-speed propulsion device, butterfly stirring device. Low-speed part is divided into anchor stirring, paddle stirring, spiral stirring, helical ribbon stirring, rectangular stirring and so on. Any combination has its unique mixing effect. It also have vacuum and heating function and temperature inspect function
Application
Designed for syringe filling of viscous solder paste
