Double Planetary Mixers - - MAXWELL
Product details of the double planetary mixers
Quick Overview
MAXWELL double planetary mixers shows the finest craftsmanship in the industry. Wuxi MAXWELL Automation Technology Co., Ltd is a leading manufacturer of Industrial planetary mixers, vacuum emulsifying mixers, glue filling machines, capping machine and silicone sealant filling machines. MAXWELL has over 18 years of expertise and has developed immensely in the research, design, manufacture, sale, and service of different Mixing Machine and Filling Equipment used for various products such as lotions, creams, paste, sauces, gel, paints, epoxy resin, lithium battery slurry, grea State-of-art production equipment and test equipment ensure the quality of this product. Wuxi MAXWELL Automation Technology Co., Ltd is a leading manufacturer of Industrial planetary mixers, vacuum emulsifying mixers, glue filling machines, capping machine and silicone sealant filling machines. MAXWELL has over 18 years of expertise and has developed immensely in the research, design, manufacture, sale, and service of different Mixing Machine and Filling Equipment used for various products such as lotions, creams, paste, sauces, gel, paints, epoxy resin, lithium battery slurry, grea The double planetary mixers developed by our company can be applied in different fields. The obvious economic benefits of the product are well-received by customers. Wuxi MAXWELL Automation Technology Co., Ltd is a leading manufacturer of Industrial planetary mixers, vacuum emulsifying mixers, glue filling machines, capping machine and silicone sealant filling machines. MAXWELL has over 18 years of expertise and has developed immensely in the research, design, manufacture, sale, and service of different Mixing Machine and Filling Equipment used for various products such as lotions, creams, paste, sauces, gel, paints, epoxy resin, lithium battery slurry, grea
Product Information
Compared with similar products, our double planetary mixers has the following major characteristics.
Product Introduce
To satisfy our customers, we also accept the machine appearance in white, or other colors. In addition, for products with high temperature requirements, customers may also choose external heating equipment or cooling equipment. In order to meet the customer's wear-resistant requirements, we also plated zirconium oxide and other materials on the metal surface. We have a full-fledged team of designers and mechanical engineers to meet the many different needs of our customers.
Please feel free to contact us for more information.
A high viscosity mixing machine is a powerful and robust equipment designed to tackle the unique challenges associated with blending materials of high viscosity. These machines are engineered with heavy-duty motors, sturdy construction, and specialized mixing elements to handle the resistance and thickness of such materials. They provide the necessary shear and force required to break down clumps, disperse additives, and achieve thorough mixing in high viscosity applications.
The double planetary mixer adopted advanced technology, which is widely used in dispersing mixing middle or high viscosity liquid-liquid/solid-solid/liquid-solid material, such as adhesives, sealant, silicone rubber, glass glue, solder paste, quartz sand,battery paste, electronic slurry, lithium battery slurry, polyurethane, coating, pigment, dyestuff, synthetic resin rubber,ointment and etc for for electronics, chemical,construction and agricultural industries. which the viscosity is app. from 5000cp to 1000000cp.
Working Principle
Planetary power mixer is a kind of new high-efficiency mixing and stirring equipment with no dead spot. It features unique and novel stirrer mode, with two or three stirrers as well as one or two auto scrapers inside the vessel. While revolving around the axle of the vessel, the stirrers also rotate around its own axis at different speeds, to achieve complicated movement of strong shearing and kneading for materials inside the vessel. Besides, the scraper inside the equipment revolves around the axle of the vessel, scraping the materials adhering to the wall for mixing and achieving better effects.
The vessel adopts special sealing structure, capable of pressurized and vacuumized mixing, with excellent exhaust and bubble removal effects. Vessel jacket can be heating or cooling according customer's requirements. The equipment is sealed excellently. The vessel cover can be hydraulically lifted and lowered, and vessel can be moved freely for ease of operation. Furthermore, the stirrers and scraper can rise with the beam and fully detach from vessel body, for ease of cleaning.
Machine Features
Planetary Mixer Structure
● Double Twist Mixing Head
● Double-layer high speed dispersing head
● Scraper
● Emulsifying head ( Homogenizer head )
● The mixing head combination forms are tailored for different process. Twist impeller blade, Dispersing disc, Homogenizer and Scraper are optional.
In the application field of the multi-function mixer, we accumulated a wealth of experience. Our product combination include the combination of high speed and high-speed, the combination of high-speed and low-speed and the combination of low-speed and low-speed. High-speed part is divided into high shear emulsification device, high-speed dispersion device, high-speed propulsion device, butterfly stirring device. Low-speed part is divided into anchor stirring, paddle stirring, spiral stirring, helical ribbon stirring, rectangular stirring and so on. Any combination has its unique mixing effect. It also have vacuum and heating function and temperature inspect function.
Various types can be configured according to customer requirements
Product Specification
| Type | Designvolume | Workingvolume | Tank inner size | Rotarypower | Revolution speed | Self-rotary speed | Disperser power | Disperserspeed | Lifing | Dimension |
| SXJ2 | 3 | 2 | 180*120 | 0.75 | 0-51 | 0-112 | 0.75 | 0-2980 | Electric | 800*580*1200 |
| SXJ5 | 7.4 | 5 | 250*150 | 1.1 | 0-51 | 0-112 | 1.1 | 0-2980 | 1200*700*1800 | |
| SX110 | 14 | 10 | 300*200 | 1.5 | 0-48 | 0-100 | 1.5 | 0-2980 | 1300*800*1800 | |
| SXJ15 | 24 | 15 | 350*210 | 2.2 | 0-43 | 0-99 | 2.2 | 0-2980 | 1500*800*1900 | |
| SXJ30 | 43 | 30 | 400*350 | 3 | 0-42 | 0-97 | 3 | 0-2980 | 1620*900*1910 | |
| SXJ50 | 68 | 48 | 500*350 | 4 | 0-39 | 0-85 | 4 | 0-2100 | Hydraulic | |
| SXJ60 | 90 | 60 | 550*380 | 5.5 | 0-37 | 0-75 | 5.5 | 0-2100 | 1800*1100*2450 | |
| SX1100 | 149 | 100 | 650*450 | 7.5 | 0-37 | 0-75 | 11 | 0-2100 | 2200*1300*2500 | |
| SX1200 | 268 | 200 | 750*600 | 15 | 0-30 | 0-61 | 22 | 0-1450 | 2400*1600*2800 | |
| SX1300 | 376 | 300 | 850*650 | 22 | 0-28 | 0-56 | 30 | 0-1450 | 3300*1300*3400 | |
| SXJ500 | 650 | 500 | 1000*830 | 37 | 0-24 | 0-48 | 45 | 0-1450 | 3700*1500*3500 | |
| SXJ1000 | 1327 | 1000 | 1300*1000 | 45 | 0-20 | 0-36 | 55 | 0-1450 | 4200*1800*3780 | |
| SXJ2000 | 2300 | 2000 | 1500*1300 | 75 | 0-13 | 0-35 | 90 | 0-1450 | 4500*2010*4000 |
Company Introduction
Over the years, Wuxi MAXWELL Automation Technology Co., Ltd has been specializing in providing high-quality double planetary mixers. We are now recognized as one of the most experienced manufacturers in the industry. Wuxi MAXWELL Automation Technology Co., Ltd owns advanced equipment and strong technical force for double planetary mixers. We have implemented effective sustainable business initiatives that are both strategic and profitable to businesses. We make plans in reducing packaging materials, cutting energy consumption, and legally handle wastes.
Our products are of reliable quality, with great cost performance and you can purchase them with confidence. If you are in need, please contact us for business discussion.
